F-00 — The Field, rev 03, open. Busbars in copper, modules in graphite, the light only where something is happening.

Copper is structure. The light is state.

Field — rev 03, on the bench

Six boards · one released, one in placement, four to route

Journal

Nothing is finished yet. This is where I write it down.

Design updates, notes from the bench, and the details that take a fortnight to get right. In the order they happened.

The Field build, in order →

  • Preamp: two volts per volt

    Preamp: two volts per volt

    The Field 25 preamp measured on the bench: 0.046 dB of gain spread from 10 Hz to 20 kHz, 1.1° of phase…

  • All sixty-four states

    All sixty-four states

    Sixty-four codes, one staircase. The ladder now tracks within 0.2 dB to 50 dB, and below that the oscilloscope — not the…

  • The error was never in the resistors

    The error was never in the resistors

    Two new boards, resistors ten times better, and the same 32 dB error. The fault was a ground reference carrying relay current…

  • Attenuator — Test Report

    Attenuator — Test Report

    6 binary stages, 64 attenuation codes, and a result that 1% resistors cannot explain. What the prototype attenuator actually measured.

  • Volume control: the stepped ladder attenuator

    Volume control: the stepped ladder attenuator

    Twelve resistors, seven relays and no wiper on any track, that is the attenuator board. It has one property to get right,…

  • The design maths of 25 W

    The design maths of 25 W

    Twenty-five watts is early in the watt spectrum, an adolescent number. Every part of this machine is a consequence of it: ten…

  • Half a century of electronics

    Half a century of electronics

    A crystal receiver in a kitchen, fifty years of detours, and one small amplifier that has to be repairable by somebody who…

  • Ombrier pebble

    Ombrier pebble

    Pebble: compact, local and dense, the family’s smallest form. I have lots of ideas for Ombrier but want to start where I…

  • The LEAR Amp

    The LEAR Amp

    A wooden chassis, made in an image app. The photographs appear further down the page. in 2017 I designed the LEAR Amp.…
